inTEST Thermal Solutions

www.intest-thermal.com

inTEST Thermal Solutions provides Thermal Products for Environmental Test, Process Chillers and Semiconductor Test Applications.

  • No LN2 or LCO2 required
  • -100 to +300°C
  • Programmable transitions, up to 15°C/sec
  • 1.0°C accuracy
  • Extended reach for easy DUT access
  • Integrated purging system prevents moisture buildup on the DUT

Thermostream Configurations

Model

ATS-505, 605



ATS-515, 615

ATS-525, 625

LN2 or LC02 not required Not required Not required Not required
Temperature Range (at thermal head) -20 to +225°C -45 to 225°C -60 to +225°C
System Airflow Output

4 to 10 scfm

1.9 to 4.7 I/s

4 to 10 scfm

1.9 to 4.7 I/s

5 scfm (2.4 I/s)

Fixed Flow
Transition Rates

0 to +125°C,<3 min

+125 to 0°C, <4 min

-40 to +125°C,<12 sec

+125 to -40°C, <40 sec

-40 to +125°C,<12 sec

+125 to -40°C, <40 sec



Model

ATS-535, 635



ATS-545, 645

ATS-710, 810

LN2 or LC02 not required Not required Not required Not required
Temperature Range (at thermal head) -60 to +225°C -80 to +225°C -80 to +225°C
System Airflow Output

5 scfm (2.4 I/s)

Fixed Flow

4 to 18 dcfm (1.8 to 8.5 I/s)

Continuous

4 to 18 scfm(1.8 to 8.5 I/s)

Continuous
Transition Rates

-40 to +125°C,

<12 sec

+125 to -40°C, <40 sec

-55 to +125°C,

<10 sec

+125 to -55°C, <10 sec

-55 to +125°C,

<10 sec

+125 to -55°C, <10 sec



Model

ATS-730, 830





ATS-750, 850

ATS-770, 870

LN2 or LC02 not required Not required Not required Not required
Temperature Range (at thermal head) -90 to 225°C -90 to +300°C -100 to+225°C
System Airflow Output

4 to 18 scfm

(1.8 to 8.5 I/s)

Continuous

4 to 18 scfm

(1.8 to 8.5 I/s)

Continuous

4 to 12 scfm

(1.8 to 5.6 I/s)

Continuous
Transition Rates

-55 to +125°C,

<10 sec

+125 to -55°C, <10 sec

-40 to +125°C,

<12 sec

+125 to -40°C, <40 sec

-55 to +125°C,

<10 sec

+125 to -55°C, <10 sec

Incorporating;

  • Temptronic
  • Thermonics
  • Sigma Systems.

Temptronic ATS Series ThermoStreams Providing Accurate, Controlled Temperatures at the Test Site from -95°C to +300°C.

Temptronic's ThermoStreams are portable systems that deliver clean dry air for precision temperature testing or conditioning of electronics (ICs, MEMS, transceivers, or circuits) and materials. No other systems can bring your test subjects to temperature faster with precise control.

With rapid thermal cycling or long saturation at a precise temperature, these systems optimize throughput for characterization, verification, thermal shock or failure analysis applications – at the test bench or on the production floor.



NEW THERMOSTREAM ECO-710M


Ultra Quiet Thermal Testing System


Click Here for Datasheet

ATS-750-M-THERMOSTREAM


High Tempertaure Testing System


Click Here for Datasheet

HOOD STYLE THERMOCHAMBER

Click Here for Datasheet



NEW DCP 1 & DCP 2 Benchtop Precise and Fast IC Temperature Testing

DCP 101:

  • 20W capacity at -40c
  • -55 to 175c
  • 25 to -40c <2.5min



Click Here for Datasheet

DCP 102:

  • 55W capacity at -40c
  • -65 to 175c
  • 25 to -40c <35 seconds



Click Here for Datasheet

Thermonics Precision Temperature Forcing Systems (PTFS) have been discontinued and replaced by the new ATS Series ThermoStream Systems.

Sigma Systems Temperature Controllable Convection Chambers and Hot/Cold Plates.
