High Quality, Microelectronic Coil Inductors. Broadband Conical Inductors, Fixed and Tuneable Inductors, RF & Microwave Air Coil and Spiral Chip Inductors for Space, Aerospace, Defence and Commercial Applications.

Piconics is a world-class supplier of high-quality microelectronic coil inductors for a wide variety of applications in the space, military, telecom, test & measurement and medical electronics industries.



Broadband Conical Inductors

Micro CCM Broadband Conical Inductor

Features

  • Substrate Mounted for Chip and Wire Applications
  • Broadband performance to 40 GHz
  • Integrated 50 Microstrip
  • Low Insertion Loss - .35 dB
  • Perfect for Bias Tee Applications



Please Click Here For Datasheet

Micro SMT Broadband Conical Inductor

Features

  • Smallest SMT Conical Available
  • Broadband performance to 65+ GHz
  • SMT style for volume manufacturing
  • Low insertion loss - .35 db
  • Perfect for Fibre Optic Applications



Please Click Here For Datasheet



CCM Broadband Conical Inductor

Features

  • Substrate Mounted for Chip and Wire Applications
  • Broadband performance to 40 GHz
  • Integrated 50 Microstrip
  • Low insertion Loss - .35 dB
  • Perfect for Bias Tee Applications



Please Click Here For Datasheet

Micro Series Broadband Conical Inductors

Features

  • Broadband width past 40 GHz
  • Low Inductance with current handling up to 800 mA
  • Micro - size for small packages
  • Low Insertion Loss across band (<0.35 dB Typical)



Please Click Here For Datasheet


Fixed & Tuneable Inductors

RF & Microwave Air Coils

MG Series Gold High Frequency Air Coils

Features

  • Micro Sized Pure Gold Air Coils
  • Inductance Values From 8 nH
  • Precision Insulation Removal for Repeatable Mounting
  • Extremely Low Insertion Loss
  • Perfect for High Frequency Filters



Please Click Here For Datasheet

MK Series Copper High Frequency Air Coils

Features

  • Micro Sized Gold Plated Copper Coils
  • Inductance Values From 8 nH
  • Precision Insulation Removal For Repeatable Mounting
  • Extremely Low Insertion Loss
  • Perfect For High Frequency Filters



Please Click Here For Datasheet



Spiral Chip Inductors

Click here for the Piconics General Inductor Brochure



Click here for the Piconics Space Brochure



Piconics specializes in miniature MIL-Spec grade inductors along with tight tolerance, fine awg windings such as the Broad-band Conical and Microwave Air Coil Inductors.

Piconics keeps the innovative spirit alive by continuing to work with industry leaders in microelectronics to provide inductor solutions to the most challenging problems.

Click here for the Piconics Engineering Kit Brochure

The Engineering team at Piconics continues the philosophy of promoting and innovating high-quality microelectronic inductors for the industries most cutting edge applications.
